Hose Reclaimer
Hose Reclaimer
Couldn't load pickup availability
Description
Description
Reclaimer Features
- Single Reel included, can be adjusted to suit up to 3 reels
- Fits 200m hoses: 50mm, 63mm or 80mm
- Power Take Off (PTO) rewinding system
- Reduction gearbox reduces PTO speed, with hardened drive gears
- Adjustable speed relative to PTO
- Fully adjustable roller guide to feed hose onto each reel
- Tow ball at rear to attach Vaughan Irrigator
- Powder coated frame
The Vaughan Irrigators Hose Reclaimer is a mobile trailer that assists farmers in retrieving and deploying irrigation hoses. It accommodates up to three reels, each holding 200m hoses of 50mm, 63mm, or 80mm diameters. Powered by a tractor’s PTO, it features a reduction gearbox for controlled rewind speed. The adjustable roller guide ensures even hose distribution on the reels. Disengaging the PTO allows easy hose deployment. With a powder-coated frame for durability, the hose reclaimer offers a time and labor-saving solution for hose management in farming.
Performance Indicators
| Nozzle | Flow lps | PSI | Wetted Width Metres |
Area Covered Hectares/100m Run |
Application Rate mm – 2 Hours |
Application Rate mm – 3 Hours |
Application Rate mm – 6 Hours |
|---|---|---|---|---|---|---|---|
| 5/16" | 1.2 | 10 | 16 | 0.18 | 4.8 | 7.2 | 14.4 |
| 1.4 | 15 | 19 | 0.23 | 4.7 | 7.1 | 14.1 | |
| 1.6 | 20 | 22 | 0.26 | 4.6 | 6.9 | 13.8 | |
| 1/2" | 2.8 | 10 | 17 | 0.19 | 10.4 | 15.6 | 31.2 |
| 3.6 | 15 | 20 | 0.23 | 10.6 | 15.9 | 31.8 | |
| 4.0 | 20 | 23 | 0.27 | 10.8 | 16.2 | 32.4 | |
| 5/8" | 5.6 | 15 | 18 | 0.21 | 19.6 | 29.4 | 58.8 |
| 6.4 | 20 | 21 | 0.25 | 19.1 | 28.7 | 57.3 | |
| 7.2 | 25 | 24 | 0.29 | 18.6 | 27.9 | 55.8 |
