Performance Indicators
| Nozzle | Flow lps | PSI | Wetted Width Metres |
Area Covered Hectares/400m Run |
Application Rate mm – 3 Hours |
Application Rate mm – 6 Hours |
Application Rate mm – 9 Hours |
|---|---|---|---|---|---|---|---|
| 1/2" | 10 | 30 | 34 | 1.5 | 7.4 | 14.8 | 22.2 |
| 10.8 | 35 | 37 | 1.6 | 7.4 | 14.8 | 22.2 | |
| 11.6 | 40 | 40 | 1.7 | 7.4 | 14.8 | 22.2 | |
| 5/8" | 15.6 | 30 | 36 | 1.5 | 10.9 | 21.8 | 32.7 |
| 16.8 | 35 | 39 | 1.7 | 10.9 | 21.8 | 32.7 | |
| 18 | 40 | 42 | 1.8 | 10.9 | 21.8 | 32.7 | |
| 3/4" | 22.4 | 30 | 38 | 1.6 | 14.9 | 29.8 | 44.7 |
| 24 | 35 | 41 | 1.8 | 14.9 | 29.8 | 44.7 | |
| 26 | 40 | 44 | 2.0 | 14.9 | 29.8 | 44.7 |
