Vaughan Standard MKII Irrigator 11m Boom, 300m x 4mm Cable
Vaughan Standard MKII Irrigator 11m Boom, 300m x 4mm Cable
Regular price
$7,490.00 AUD
Regular price
Sale price
$7,490.00 AUD
Quantity
Couldn't load pickup availability
Description
Description
The Standard MkII irrigator has 300 metres of cable and 11 metre galvanised arms, designed for simple mechanical operation and easy speed adjustment across four settings. Its pivot points are housed in greased bearings, eliminating the need for a gearbox or water winch to reduce common issues. This irrigator is perfectly suited for low-pressure irrigating up to 20 acres of crops and pastures or for effluent distribution.
Features
- Suitable for 5 - 20 Acres
- 11 metre boom
- 300 metre cable run
- Throws up to 40 metres
- Heavy duty components
- Ideal for both effluent and water
- 10 – 90 psi
- Automatic shut off (Optional)
Performance Indicators
| Nozzle | Flow lps | PSI | Wetted Width Metres |
Area Covered Hectares/300m Run |
Application Rate mm – 4 Hours |
Application Rate mm – 6 Hours |
Application Rate mm – 12 Hours |
|---|---|---|---|---|---|---|---|
| 1/2" | 4.0 | 20 | 30 | 1.0 | 7.9 | 11.9 | 23.7 |
| 4.4 | 25 | 34 | 1.1 | 7.9 | 11.9 | 23.7 | |
| 4.8 | 30 | 36 | 1.2 | 7.9 | 11.9 | 23.7 | |
| 5/8" | 6.4 | 20 | 30 | 1.0 | 9.4 | 14.1 | 28.2 |
| 7.2 | 25 | 35 | 1.1 | 9.4 | 14.1 | 28.2 | |
| 7.8 | 30 | 40 | 1.3 | 9.4 | 14.1 | 28.2 | |
| 3/4" | 9.2 | 20 | 30 | 1.0 | 13.7 | 20.6 | 41.1 |
| 10.2 | 25 | 35 | 1.1 | 13.7 | 20.6 | 41.1 | |
| 11.2 | 30 | 40 | 1.3 | 13.7 | 20.6 | 41.1 |
